1.Motor type: Brush type for OS-10,and brushless Motor for model OS-15S/OS-30S.
2.Multiple stirring paddle/stirring rod optional,length 27CM;metal stand with fixer optional.
3.Digital display and time setting: 0-24H for model OS-15S/OS-30S.
4.Max viscosity 16000Mpas,;Max torque: 30N.cm;Max Capacity 20L.
Model | OS-10 | OS-15S | OS-30S | OS-15Pro | OS-30Pro |
motor | Brushed motor | Brushless motor | |||
Operation mode | knob | Digital display+knob | |||
speed | 100-1000rpm | 100-1500rpm | 50-1200rpm | 100-1500rpm | 50-1200rpm |
Stepping | / | 10rpm | |||
Max mixing volume | 10L | 10L | 20L | 10L | 20L |
Rated torque | 20N.cm | 15N.cm | 30N.cm | 15N.cm | 30N.cm |
Max viscosity | 10000mPas | 8000mPas | 16000mPas | 8000mPas | 16000mPas |
Timing range | / | 0-24h | |||
Stirring rod penetration | NO | NO | YES | ||
Drill clamp diameter | 1-10mm | ||||
Power | 36W | 50W | 60W | 50W | 60W |
Size | 145*70*195mm | ||||
Voltage | 24V 1.5A | 24V 2.5A | 24V 2.5A | ||
